It is a few minutes past six, and you are in the shower. The spray is fine, and then it is not. The pressure sags, the stream narrows, and the temperature wanders, because the cold side lost more than the hot side did. Outside, a valve thunks open and a rotor starts ticking its way across the yard.
Nothing broke. One well is being asked to do two jobs in the same minute, and you find out about it in the shower. What you cannot tell from where you are standing is whether the well truly cannot supply both, or whether the two demands simply landed on top of each other. Those answers lead to very different work, and one morning of testing separates them.
Why the Shower Is Where You Notice It First
Your house and your yard sit on opposite ends of the flow range. A rotor zone with eight heads at 1.5 gallons per minute each pulls 12 gallons per minute continuously for as long as the controller holds that valve open. A shower head is capped at 2.5 gallons per minute at 80 psi under the federal maximum, and a water-efficiency-labeled head is rated at 2.0. The zone outside is drawing five or six times as much as you are.
Everything downstream of the pump operates at a single pressure, so the two demands are not separate systems that happen to be near each other. They are one system with two openings. A centrifugal pump trades pressure for flow along its performance curve, so at 12 gallons per minute plus your shower, the pump maintains less pressure than it does at your shower alone. The common piping takes its own cut on top of that: friction loss in a pipe climbs with flow raised to the 1.85 power in the Hazen-Williams formula, so tripling the flow in the shared run multiplies the loss there by about seven and a half.
Then there is the reason it surfaces in the shower before it surfaces at the kitchen sink. A shower valve blends two supplies. A few psi off the cold side moves the mix, and you feel the temperature change on your skin a good while before you would notice a sink filling three seconds slower.
What the Pressure Tank Covers, and What It Cannot
Between pump starts, your house is not drinking from the well at all. It is drinking from the pressure tank, where water sits compressed against a cushion of air behind a diaphragm. Open a tap, and the air pushes water out into the line. Pressure drops as the tank empties, and when it reaches the cut-in setting, the pump starts and refills the tank.
That arrangement is built around the way a household actually uses water, which is in short calls with gaps between them. A toilet refill is 1.6 gallons under the federal maximum for tank-type toilets, and handwashing is a matter of seconds. The tank covers those outside the stored water, and the gaps give the pump time to refill the stored water.
A sprinkler zone is a different kind of demand, a sustained draw that runs for half an hour or longer without pausing. Whatever usable water your tank gives up between cut-out and cut-in, a zone pulling 12 gallons a minute empties it in a minute or two. From that point until the controller closes the valve, the tank contributes nothing. The pump runs without stopping, and the pressure at every fixture in the house is whatever the pump can hold while it delivers that flow.
A bigger tank changes how long your house coasts before the pump has to start. It changes nothing about the thirty-eight minutes that follow.
Drawdown Against Yield: What a Long Draw Asks of the Well
A well is a hole with water standing in it, and the aquifer around it feeds that hole at a rate the ground allows. Pump at less than that rate, and the water level in the casing falls to a new, lower level and holds there as long as you keep pumping. Pump faster than the ground can feed it, and the level does not settle. It keeps falling. That drop is drawdown, and the pumping rate the well can sustain without the level reaching the pump is its yield.
The arithmetic separates the two demands. A ten-minute shower at 2 gallons per minute uses 20 gallons from the well, and the level comes back while you are making coffee. Your zone at 12 gallons per minute for 40 minutes removes 480 gallons from the same hole, with no pause anywhere. Four zones back-to-back are nearly 2,000 gallons in a single continuous block, and the well has no recovery time until the last valve closes.
If drawdown reaches the pump intake, the pump begins drawing air. Delivery turns ragged, the heads out in the yard stutter, and inside the house the pressure comes and goes in surges. A submersible motor is cooled by the water moving up past its shell, and a four-inch motor needs at least 0.25 feet a second of flow past it to stay cool. Below that, a motor turning in a broken column of water keeps making heat with nothing left to carry it away. What that same condition does to a dedicated irrigation pump running a field is a separate subject; this is the shared well feeding a house.
How Do You Tell a Scheduling Problem From a Well That Cannot Keep Up?
The two look identical in the shower and are separated by the symptom that follows. A scheduling problem follows overlap. A capacity problem follows run length.
Run one zone by itself, early, with nothing running indoors, and watch a pressure gauge for the whole cycle. Do this isolated run first, because a capacity problem is invisible while the house is also drawing: you cannot say whose demand caused the sag when both are open.
Here is what you are watching for. If pressure drops to a lower figure at the start of the run, sits flat there for the full thirty or forty minutes, then jumps back the moment the valve closes, the well is keeping up. The pump is operating at the flat part of its curve, leaving nothing left over for a second demand. Move the start time to two in the morning, and your complaint disappears, because nobody is asking for water at the same moment.
If instead the pressure keeps sliding as the run goes on, and the worst of it is in the last third rather than the first, the well is losing ground. Look for air or grit at the tap late in the cycle, and time how long the system takes to return to cut-out after everything has stopped. Recovery that takes considerably longer than it does after filling a bathtub points the same way. Moving the schedule changes nothing here except who is awake to notice.
What Your Number Pair Means While a Zone Runs
Your irrigation controller has no wire to your pump. A dedicated irrigation pump gets a pump start relay that the controller energizes; zones teed into the pressurized house side have no such connection. Your controller opens a valve, water leaves the system, and the switch meets that falling pressure exactly as it would a bathtub filling. It never learns a zone is running, and it acts on nothing but the pressure your shower also feels.
Cut-in is the floor your fixtures see between pump calls. On a 40/60 system, any reading under 40 psi means the pump is running right then and not keeping ahead of what is open. Watch the gauge through a full zone: if the needle sits under cut-in the whole run and never reaches cut-out, the contacts never opened and the pump never caught up.
Raising cut-out asks the pump for more pressure while it still delivers the same gallons to the zone, which moves it back along its curve toward less flow. It adds no water to the well. The pair your system came set at is marked on the label under the switch cover, and it is worth writing down before anyone changes it, because nobody can measure that starting figure after the fact.
A pump control box carries a danger label for hazardous voltage, and the terminals inside it and behind the pressure switch cover stay live whenever the pump breaker is on. Reading that number pair with the covers off is a technician's work.
Frequently Asked Questions
A larger tank gives you more stored water before the pump starts, and that is all it gives you. Once the pump runs continuously to feed a zone, the tank sits at whatever pressure the pump is holding, its diaphragm collapsed against the outlet with the air charge expanded through the whole shell, and it neither adds water to the line nor takes any out. It begins refilling only when your demand drops back below what the pump produces.
It removes the overlap, which resolves the whole problem if your trouble is scheduling. It does not add gallons. Stack five zones from midnight to four and the well still sees four hours of continuous draw with no pause to recover in. Check your controller's manual for a cycle-and-soak setting, which splits a zone into shorter runs separated by soak intervals and lets the water level come back between them.
Not if it draws on the same well. Two pumps in one casing still pull from one aquifer through one borehole, so the yield question is unchanged and you have added a second motor competing for the same water. What changes the arithmetic for you is an above-ground storage tank, filled around the clock at whatever rate the well sustains, with its own pump feeding the zones out of it.
It can be, and the mechanism is the standing water level rather than the yield. Available drawdown is the distance from the standing level down to your pump intake, the room you have before it is uncovered. When recharge is low that level sits lower and there is less room, so a schedule that worked before runs out of it. In a wet stretch the level rises and your controller's rain sensor holds the zones off.
Not necessarily. A head keeps throwing water at pressures well under the one it was chosen for, so the yard can look right while the house does not. Your nozzle's design pressure is printed in the manufacturer's nozzle performance chart, alongside the radius and flow at each pressure. Compare that chart against what your system holds during a run and you can see whether the heads are under their design point while looking normal from the driveway.
More than the drift itself suggests. The usable fraction follows Boyle's law on absolute pressure, gauge plus 14.7: at a 38 psi precharge under a 40/60 switch it is 52.7 x (1/54.7 - 1/74.7), about 0.26, so an 85-gallon tank gives up roughly 22 gallons of tank drawdown. Let that charge fall to 28 psi and the fraction drops to 0.21, near 18 gallons, and your house coasts that much less before the pump has to start.
If the pressure keeps sliding through a single zone with the house idle, a flow test at the wellhead is the next step — it establishes the gallons per minute your well will actually sustain, a figure that no amount of re-scheduling the zones can reveal. Perry-Pump Repair Service LLC serves Lake Butler, Gainesville, Alachua, and Lake City. Call (352) 320-2412.
